Portable Tertiary Impact Crushers
Portable Tertiary Impact Crushers are wheel-mounted rock crushing machines, engineered for tertiary crushing applications. Equipped with a horizontal shaft impact crusher and a feed hopper with belt feeder, it is designed especially for processing soft and medium-hard materials, such as limestone and recycled materials, and ideal for the production of high grade concrete and asphalt aggregate. They can be used in multistage crushing process or as a stand-alone unit crushing pre-crushed material.
Applications
QUARRIES
INDUSTRIAL MINERALS
- Production of aggregates for concrete and asphalt plants,
- Production of manufactured sand
- Shaping of flaky aggregates to obtain cubical aggregates
INDUSTRIAL MINERALS
- With minimum capital and operational costs
- Excellent particle shape down to micron sizes
Why MEKA Portable Tertiary Impact Crushers?
Production of manufactured sand with low filler content
Large unobstructed feed opening, triple heavy-duty breaker plates
Simple and easy hydraulic assisted gap adjustment
Symmetrical design of the crusher, the rotor’s direction of rotation can be reversed
Self contained electrical switchgear cabinet mounted on the semi-trailer, with controls for feeder, crusher and discharge conveyor.
Electrical switchgear cabinet can be located on the ground during operation,
2” / 3 ½” King-pin, double or triple-axle bogie with air-brakes, ABS and travel lights, mudflaps.
Portable Tertiary Impact Crushers Technical Specifications
MP 1110TI |
MP 1115TI |
||
| BELT FEEDER | |||
| Model | MBF 1060 | MBF 1460 | |
| Width | 1 000 mm | 1 400 mm | |
| Length | 6 000 mm | 6 000 mm | |
| Motor Power | 2 x 5.5 kW | 2 x 7,5 kW | |
| Hopper Volume | 5 m³ | 7 m³ | |
| TERTIARY IMPACT CRUSHER | |||
| Model | MTI 1110 | MTI 1115 | |
| Rotor Dimensions | Ø 1 100 x 1 000 mm | Ø 1 100 x 1 500 mm | |
| Maximum Feed Size | 150 mm | 150 mm | |
| Capacity* | up to 250 mtph | up to 320 mtph | |
| Motor Power | 250 kW (50 Hz) | 315 kW (50 Hz) | |
| DISCHARGE CONVEYOR | |||
| Belt Width | 1 000 mm | 1 200 mm | |
| Length | 7 000 mm | 7 000 mm | |
| Motor Power | 11 kW | 15 kW | |
| TRANSPORT DIMENSIONS | |||
| Length | 15 500 mm | 15 500 mm | |
| Width | 2 400 mm | 3 000 mm | |
| Height | 4 300 mm | 4 300 mm | |
| Weight | 32 000 kg | 38 000 kg | |
| OPERATING DIMENSIONS | |||
| Length | 13 600 mm | 13 600 mm | |
| Width | 3 900 mm | 4 500 mm | |
| Height | 5 100 mm | 5 100 mm | |
*For material weighing 1.6 t/m³ or 100 lbs/ft³.
Capacity values are indicative only, crusher performance may vary depending on the feed gradation, feed moisture content,crushability of the material, crusher rpm, installed power and the crushing circuit design.
Portable Tertiary Impact Crushers Gallery
What is Portable Tertiary Impact Crusher?
The portable tertiary plant is a wheel mounted unit with feed hopper, belt feeder,horizontal shaft impact crusher,discharge belt conveyor.
Types of Portable Tertiary Impact Crushers
How Does Portable Tertiary Impact Crushers Work?
Advantages of Using Portable Tertiary Impact Crushers
Portable Tertiary Impact Crushers Processes Applications
The material is fed to the tertiary horizontal shaft impactor by belt conveyor.The materials are crushed by the impact force generated by the blowbars mounted on a rotor.With the impact of the material on the blowbars on the rotor, the material hits the opposite breaker plates and a second crushing takes place.Unlike secondary and primary impact crushers, the rotor of the tertiary impact crusher can rotate in both directions.
In addition to the general advantages of the tertiary horizontal shaft impact crusher , such as production of high amount of sand with low filler content, the advantages of being portable are as follows;
Compact design,
Ready for operation: Can be commissioned and started up quickly
No concrete work: No need for excess concrete and site preparation
Quick and easy site change for another project.
Energy cost per ton of product produced is low.
Tertiary impact crushers produce more cubical-shaped end products.
Portable horizontal shaft impact crusher with belt feeder are used to produce products to be used in a variety of diverse industries such as asphalt, concrete and recycling .
