M60 Mobile Concrete Batching Plants
M60 Mobile Concrete Batching Plants
THE BEST CHOICE FOR PRACTICAL CONCRETE PRODUCTION ON SHORT-TERM PROJECTS
M 60 model is the optimum choice for moderate production on temporary work sites. The durability offered by stationary batching plants coupled with the flexibility of the mobile design make it an unmatched solution for every professional organization. Installation requires minimum or no foundations, thus reducing operational costs and bringing mobility to a new level.
PLANT CAPACITY
CONCRETE MIXER
Shaft/Twinshaft/Planetary Mixer
1,0 m³ / cycle
37 kW / 2x 18,5 kW / 4
STORAGE & FEEDING
4x 10 m³ Cross Type
Ramp or Pre-Feeding Sys
HOPPERS
500 kg
200 kg
20 kg
HIGHLIGHTS / M60
- Ultra Performance and Flexibility
MEKA M 60 Mobile concrete batching are flexible, durable and offer class-leading productivity. The model is preferred by contractors for temporary works, and by ready-mix firms for its corporate flexibility. - Unique Single-Chassis Design
All of the operational equipment required for production is installed on the main single chassis of the mobile plant and is transported in place. - Transport with a single tow truck
The M 60 plant, comprising two complete sets of screw conveyors, filters and other silo equipment, can be transported aboard a single trailer truck. All MEKA mobile batching plants are equipped with two axles to ensure good weight distribution. - Quick Start Up Time
To reduce installation time and crane operations, the main components in the M60 mobile plant are installed, pre-wired and tested in the production facilities. - Minimum Foundation Required
Thanks to their design, Meka mobile batching plants require no or minimal foundations, thus reducing the operating costs and bringing mobility to a new level. - 180 Degree Truck Mixer Aproach
Due to the heavy duty chassis design, the M60 MEKA requires no front supports. The absence of front supports not only reduces the installation time, but also brings useful operational characteristics, allowing mixer trucks to approach from three angles (180 degrees) and drive through. This feature is very useful for strict and narrow sites.
M60 / TECHNICAL SPECIFICATIONS
Metric |
Imperial |
|
| Compacted Output | 80 m³/h | - |
| Mixer Capacity ( Compacted Concrete ) | 70,0 m³ /cycle | - |
| Mixer Type | Single Shaft/Twinshaft/ Planetary Mixer | |
| Mixer Motor Power | 37 kW /2x 18,5 kW/ 45 kW | - |
| Aggregate Bins | 4x 10 m³ Cross Type | - |
| Aggregate Feeding | Ramp or Pre-Feeding System | |
| Aggregate Transfer | Belt | - |
| Air Compressor | Piston Type (55,5 kW) | - |
| Cement Weighing Hopper | 5000 kg | - |
| Water Weighing Hopper | 2000 kg | - |
| Additive Weighing Hopper | 200 kg | - |
| Cement Screw Conveyor | Ø 219 x 111.500 mm | - |
Click for the comparison table of technical specifications of Meka Mobile Plants.
